Tension Fitting For Covered Conductor

Tension Fitting for Covered Conductor – MM Powerline Transmission (MMPT)

MM Powerline Transmission (MMPT) is a trusted manufacturer and supplier of high-performance tension fittings for covered conductors, designed to ensure secure, reliable, and long-lasting mechanical support in overhead power distribution systems.

Our MMPT tension fittings are specially engineered for use with covered conductors, providing excellent tensile strength and corrosion resistance in demanding environmental conditions. These fittings play a critical role in maintaining the structural integrity of aerial bundled cables (ABC) and covered conductor systems, especially under mechanical load and thermal stress.

At MMPT, our tension fittings are manufactured with precision from high-quality materials such as aluminum alloy and galvanized steel, ensuring compatibility and durability with various covered conductor applications across voltage levels. Each tension clamp or dead-end fitting is rigorously tested to comply with industry standards, guaranteeing optimal performance and safety.

Our tension fittings are widely used in:

Rural and urban overhead power distribution lines
Forest and coastal areas prone to high corrosion
Areas requiring enhanced electrical safety with covered conductors

What is a Ball Link?

A ball link is a specialized connector used in overhead power transmission lines. It features a rounded ball design that allows for flexible connections between conductors and other components. This unique design provides a secure attachment point while accommodating
movement due to environmental factors.

Key Features of MMPT Tension Fittings:

Designed specifically for covered conductor systems
High mechanical strength and electrical performance
Corrosion-resistant materials suitable for harsh climates
Easy installation and low maintenance
Compatible with a wide range of conductor sizes and types

Choose MM Powerline Transmission (MMPT) for reliable and cost-effective tension fittings for covered conductors. Our commitment to quality, innovation, and customer satisfaction makes us a leading tension fitting manufacturer in India and a preferred partner for power utilities and infrastructure developers.

Contact us today to learn more about our complete range of covered conductor hardware fittings, including tension clamps, suspension clamps, and other accessories.

BOQ

SL. NO	DESCRIPTION	QTY	MATERIAL
1	TWISTED STRAP	1 NOS	MILD STEEL, HDG
2	BALL EYE	1 NOS	STEEL, HDG
3	SOCKET EYE	1 NOS	STEEL, HDG
4	TENSION CLAMP WITH ANTI TRACKING DEVICE	1 NOS	AL. ALLOY/HEAT & UV STABILIZED THERMOPLASTIC/MILD STEEL HDG
5	BOLT, NUT & WASHER	1 NOS	STEEL, HDG

TECHNICAL DATA

ALL DIMENSIONS ARE IN MM.
STANDARD SPECIFICATION : EN 50397-2 & NFC 33-041
CLAMP SUITABLE FOR 100 SQ.MM. AAAC XLPE COVERED CONDUCTOR (11KV)
UTS OF HARDWARE : 70KN.
UTS OF TENSION CLAMP : 30 KN.
SLIP STRENGTH OF TENSION CLAMP : 5KN.
BALL & SOCKET DESIGNATION : 16MM & 16MM B.
FERROUS PART HOT DIP GALVANIZED AS PER IS:2629/IS:2633/IS:4759.
GENERAL TOLERANCE : ±5%

AVAILABLE FOR THE FOLLOWING CONDUCTORS

For ACSR

SL. NO	ACSR code	CONDUCTOR DIA.
1	RACCOON	12.27
2	DOG	14.15
3	LEOPARD	15.84
4	COYOTE	15.86
5	TIGER	16.52
6	WOLF	18.13
7	ORIOLE	18.82
8	LYNX	19.53
9	LARK	20.47
10	PANTHER	21.00
11	LION	22.26
12	BEAR	23.45
13	GROSBEAK	25.16
14	TEAL	25.24
15	GOAT	25.97
16	ANTELOPE	26.73
17	KUNDAH	26.80
18	SHEEP	27.93
19	DRAKE	28.14
20	ZEBRA	28.62
21	DEER	29.89
22	CAMEL	30.15
23	ELK	31.50
24	MORKULLA	31.68
25	MOOSE	31.77
26	BERSIMIS	35.05
